Surge arrester V10-C 3+NPE OBO

  • Model:
  • Surge Arrestor , 3-pole + NPE
  • Request Code:
  • 5094920

Protection against lightning and severe vibration device, Class C + D , type II + III , high current conductivity and long life, with function display , Arresting capacity to 10kA per pin (8/20) . Appliction : industry , equipotential bonding and device protection in main and subdistributors . On the base of standard, installed arrestor gap between Class C and Class D must not be less than 5 meters. Observe the distance, the problems that are created by the State Board for fixing, “Combination arrestor C+D“ can be used. Other features of this device are : - With Maximum Continuous Operating Voltage (Uc=280V) - 5-year warranty - VDE test mark Bornika is the official representative of OBO Bettermann in the fields of consultation, sales and distribution of power industry products including class Class C + D , type II + III .

Share in social networks

Instagram Telegram Aparat Linkedin

Surge arrester V10-C 3+NPE OBO Specification

IP IP20
Surge arrester class Class C+D (Type II+III)
Mounting Type DIN rail
Voltage protection level (Up) <1.1kV
Nominal Voltage (Un) 230V
Nominal discharge current(8/20) 10kA
Total discharge current(8/20) 40kA
Response time <25ns
maximum back-up fuse 125A

Surge arrester V10-C 3+NPE OBO Catalogs

Download Catalog : LPZ rev-01 320 KB

Download Catalog : V10-C 3+NPE OBO 2620 KB

Surge arrester V10-C 3+NPE OBO More Description

V10-C 3+NPE Surge arrestor V10 , 280V , 3-pole + NPE Item No : 5094 92 0 Degree of protection of enclosure : IP20 Temprature range : -40 - +80

Surge arrester V10-C 3+NPE OBO Price

Please call ...
