Arrester type SafeTec T2 1+1

  • Model:
  • SafeTec T2
  • Request Code:
  • 59.0186 - 59.0190 - 59.0189 - 59.0126 - 59.0127 - 59.0128 - 59.0274

Arrester type SafeTec T2 1+1 has 2 disassembly cartridge includes 1 MOV and 1 GDT. This product designed for high reliability surge protection from damage caused by electrical surges. This product used for TT, TN-S network systems and offers a safe solution in a standard and compact DIN Rail design. The SafeTec product line includes high energy MOV and GDT technology, and is available in a wide range of configurations to meet any application. SafeTec Features: Location of Use: Sub-distribution Boards Protective elements: MOV and GDT Industry standard DIN rail design High TOV Immunity No arcing during disconnection IEC/EN Category: Class II / Type 2 Safety: Patented Current Limiting Five year warranty Pluggable Design Certified to IEC 61643-11:2011 and / or EN 61643-11:2012, UL 1449 4th Edition Bornika is the exclusive agent of Raycap in the fields of consultation, sales and distribution of power industry products including surge arrester Class C, Type II.

Share in social networks

Instagram Telegram Aparat Linkedin

Arrester type SafeTec T2 1+1 Specification

Dimensions 109x115x352 mm
IP IP 20
Approximate Weight 235 ... 252g
Surge arrester class Class C (Type II )
Mounting Type DIN rail
Voltage protection level (Up) (L - N) / (N - PE) : 800 V / 1500 V ... 1750 V / 1500 V
Nominal Voltage (Un) 60 ... 277 V
Nominal discharge current(8/20) (L - N) / (N - PE) : 20 kA / 40 kA
Total discharge current(8/20) (L - N) / (N - PE) : 50 kA / 65kA
Response time (L-N)/(N-PE) : < 25 ns / < 100 ns
maximum back-up fuse 315 A / 250 A gG

Arrester type SafeTec T2 1+1 Catalogs

Download Catalog : Arrester type SafeTec T2 1+1 datasheet 2809 KB

Download Catalog : Raycap main catalogue 46139 KB

Download Catalog : SafeTec Connection Configuration 2044 KB

Arrester type SafeTec T2 1+1 More Description

Arrester type SafeTec T2 1+1 Price

Please call ...
