OBO Bettermann Co.

  • Country: Germany
  • Establishment : 1911

Great family Betterman Germany was founded in 1911. The company with 104 years of experience and more than forty thousand different products in terms of equipment protection and distribution of electrical energy with the slogan ((thought continued)) with a turnover of over 500 million euros per year and more than 3,000 employees around the the world is one of the world's best-known providers in the following seven areas of work: Connection and fastening systems Transient and lightning protection systems Cable support systems Fire protection systems Cable routing systems Device systems Underfloor systems Bornika is the exclusive agent of OBO Bettermann in the fields of consulation, sales and distribution of power industry products and surge arrester including Class B, Combination B+C, Class C, Combination C+D, Class D, solar batteries, phone lines, coaxial cable , network cables, explosion-proof Barrier & Spark Gaps, Surge Arrestor's Counter and lightning arrester,data network,coupling earthing systems,earth terminal or load trminal ,measurement Relays of ground resistance,

OBO Bettermann Products

  • Surge arrester V10 COMPACT 150 OBO
  • Protection against lightning and severe vibration device, Class C + D , type II + III , high current conductivity and long life, with function display , suitable for TN, TT network systems , Arresting capacity to 10kA per pin (8/20) , With Maximum Continuous Operating Voltage (Uc=150V) , Appliction : industry , housing and device protection of rotary current sysrems .
  • Surge arrester V10 COMPACT 255 OBO
  • Protection against lightning and severe vibration device, Class C + D , type II + III , high current conductivity and long life, with function display , suitable for TN, TT network systems , Arresting capacity to 10kA per pin (8/20) , With Maximum Continuous Operating Voltage (Uc=255V) , Appliction : industry , housing and device protection of rotary current sysrems .
  • Surge arrester V10 COMPACT 385 OBO
  • Protection against lightning and severe vibration device, Class C + D , type II + III , high current conductivity and long life, with function display , suitable for TN, TT network systems , Arresting capacity to 10kA per pin (8/20) . Appliction : industry , housing and device protection of rotary current sysrems . On the base of standard, installed arrestor gap between Class C and Class D must not be less than 5 meters. Observe the distance, the problems that are created by the State Board for fixing, “Combination arrestor C+D“ can be used.
  • Surge arrester V10COMPACT-AS OBO
  • Protection against lightning and severe vibration device, Class C + D , type II + III , high current conductivity and long life, with function display , suitable for TN, TT network systems , Arresting capacity to 20kA per pin (8/20) , Appliction : industry , housing and device protection of rotary current sysrems . On the base of standard, installed arrestor gap between Class C and Class D must not be less than 5 meters. Observe the distance, the problems that are created by the State Board for fixing, “Combination arrestor C+D“ can be used.
  • Surge arrester V20-C 1+NPE-280 OBO
  • As the second phase of the protection circuit is used and the ability to resist a sudden flow of 40 kA with wave form 8/20 μs to have repetitions. The equipment in the power distribution (power), power dividers and sub-distributors are installed.
  • Surge arrester V20-C 2+NPE-280 OBO
  • As the second phase of the protection circuit is used and the ability to resist a sudden flow of 60 kA with wave form 8/20 μs to have repetitions. The equipment in the power distribution (power), power dividers and sub-distributors are installed.
  • Surge arrester V20-C 3+NPE-280 OBO
  • As the second phase of the protection circuit is used and the ability to resist a sudden flow of 120 kA with wave form 8/20 μs to have repetitions. The equipment in the power distribution (power), power dividers and sub-distributors are installed.
  • Surge arrester C 25-B+C 1OBO
  • As the second phase of the protection circuit is used and the ability to resist a sudden flow of 30kA with wave form 8/20 μs to have repetitions. The equipment in the power distribution (power), power dividers and sub-distributors are installed.
  • Surge arrester V25-B+C 1-280 OBO
  • Combination arrestor , protection of single-phase , with a visual representation of performance On the base of standard, the gap between surge arrestor Class B and Class C installed, must not be less than 10 meters. Observe the distance, the problems that are created due to make the boards for fixing it, "Combination arrestor B+C" can be used. Some Class B arrestors have certain technology, that Class C arrestor can be installed immediately next to it.
  • Surge arrester V25-B+C 1+NPE+FS OBO
  • combination arrester , phase protection + neutral , with remote signalling . On the base of standard, the gap between surge arrestor Class B and Class C installed, must not be less than 10 meters. Observe the distance, the problems that are created due to make the boards for fixing it, "Combination arrestor B+C" can be used. Some Class B arrestors have certain technology, that Class C arrestor can be installed immediately next to it.
